Specification
Reticle: 1.5 MOA
Objective Lens Diameter: 23 mm
Illumination Source: High-efficiency LED
Lens Material: Multi-coated glass
Multi-coated glass: 1×
Eye Relief: Unlimited
Click Value: 1 MOA/click
Parallax: ≤1 MOA per side
Parallax Setting Distance: 100 yards
Optical Axis Height: 40.4 mm (high mount); 22 mm (low mount)
Adjustment Range: U: ±45 MOA;R: ±45 MOA
Shock Resistance: 2,000 G
Brightness Settings: 8 daylight settings + 2 night-vision settings
Housing Material: 6063 CNC-machined aluminum alloy
Dimensions (L × W × H): 52 × 42.7 × 69 mm (with high mount); 52 × 42.7 × 51 mm (with low mount)
Net Weight: 135 g
Battery: CR2032; side-loading; battery life: over 100,000 hours at low brightness
Waterproof: IPX7
Operating Temperature: -20 °C to 40 °C (−4 °F to 104 °F)
Storage Temperature: -30 °C to 50 °C (−22 °F to 122 °F)
Mounting Interface / Mount Type: Compatible with both high and low mounts
Feature
Ultra-short tube design; side-loading CR2032 battery; 1 MOA click value; motion-activated wake-up.
Motion Sensor：1. Auto shutoff after 2 minutes of inactivity 2. Instant power-on upon motion detection
Accessories ( included )
1*TS 4 Red Dot Sight
1*83’’ Mount Base
1*Cleaning Cloth
1*Lens Cover
1*Allen Wrench
2*CR2032 Batteries
